Structures — Part 1
🏠 Home Lecture 20: Structures
Think First ⚡

Before We Begin — A Quick Challenge!

You are building a Student Management System. You need to store a student's name, roll number, and marks. What is the problem with using separate variables?

💡 Challenge: Store info for 100 students

What is the smartest way to keep a student's info in a single unit?
3 separate arrays — name[], roll[], marks[]
struct — group everything into a custom data type
Just create one large char array
Use pointers for every variable
problem.cThe Nightmare 😱
// For just one student — it's fine char name1[50]; int roll1; float marks1; // For 100 students? Nightmare! 😭 char name1[50], name2[50], name3[50]... int roll1, roll2, roll3... float marks1, marks2, marks3... // What is a better solution?
Definition

What is a Structure?

A structure is a user-defined data type in C that groups variables of different data types under a single name. Hover on highlighted code to explore each part!

struct_definition.cHover to explore ✶
struct Student { char name[50]; // string member int roll; // integer member float marks; // float member }; ← Semicolon mandatory! // Declare a variable of type Student struct Student s1;
🧠 Core Memory Rule: A struct definition DOES NOT allocate memory — it's just a template. Memory is allocated only when you write struct Student s1;!
⚠️ Common Mistake: Forgetting the ; after a struct definition — this causes a compiler error!
Syntax Deep Dive

Declaration, Initialization & Member Access

Struct is defined — now declare variables, initialize them, and access members using the dot operator (.)!

init_access.cStep through ▶
struct Student { char name[50]; int roll; float marks; };
// Method 1: Direct init struct Student s1 = {"Abhay", 101, 95.5};
// Method 2: Assign struct Student s2; strcpy(s2.name, "Rohan"); s2.roll = 102; s2.marks = 88.0;
// Access members printf("%s", s1.name);
Step 1 of 5
📋
struct Blueprint
First, we define struct Student — 3 members: name, roll, marks. No memory is allocated yet.
💡 Dot Operator (.)
variable_name.member_name
e.g., s1.roll gives 101
e.g., s2.marks gives 88.0
Special case for Strings: s2.name = \"Rohan\" DOES NOT work directly! You must use strcpy() for strings.
Interactive WOW ⭐

Live Player Cards with struct!

Type values directly into the code below to see the struct memory update the cards in real-time!

player_cards.cLive Editor ✏️
struct Player { char name[50]; char position[10]; int jersey; int goals; float rating; }; struct Player p1, p2; // --- Initialize p1 (Player 1) --- strcpy(p1.name, ""); strcpy(p1.position, ""); p1.jersey = ; p1.goals = ; p1.rating = f; // --- Initialize p2 (Player 2) --- strcpy(p2.name, ""); strcpy(p2.position, ""); p2.jersey = ; p2.goals = ; p2.rating = f;
94
RW
MESSI
JERSEY 10
GOALS 821
93
ST
RONALDO
JERSEY 7
GOALS 873
Array of Structures

struct Student cls[5] — The Entire Class!

Just like int arr[5] holds 5 integers, struct Student cls[5] holds 5 complete student records! Click on any student card.

array_of_structs.cClick a card →
struct Student { char name[50]; int roll; float marks; }; struct Student cls[5] = { {"Abhay", 101, 95.5}, {"Priya", 102, 88.0}, {"Rohan", 103, 76.5}, {"Sneha", 104, 91.0}, {"Arjun", 105, 83.5}, }; // Access: cls[i].member printf("%s", cls[?].name);
👆 Click a student card
Click on a card — that student will be highlighted in the code and their struct data will appear here.
Memory: cls[0] is followed by cls[1] — all are contiguous! Total = 5 × sizeof(Student) bytes.
Loop: for(i=0;i<5;i++) printf(cls[i].name);
Examples on Structures

Structures in Action

Three real-world examples — step through them and see the output!

student_record.cStep ▶
Remember: Use struct to model real-world entities — student, book, employee all in one place!
